Failure analysis of the 60/32 32mm inner diameter bearing!

Normal bearing operation sound should be uniform, stable, and not harsh, while abnormal bearing operation sound can have various intermittent, impulsive, or harsh sounds. Firstly, one should get used to normal bearing operation sounds, and then one can grasp and judge abnormal bearing operation sounds. There are many types of abnormal bearing sounds, which are difficult to express in words and mainly rely on experience accumulation.

1. Frequent replacement of 60/32 32mm inner diameter bearing reason: Failure of lubricating grease or oil, incorrect model selection Solution: Ask the oil supplier to determine the correct type of lubricant.
2. Frequent replacement of 60/32 32mm inner diameter bearing reason: Low oil level or insufficient lubricating grease Solution: The lubricating oil must be lower than the center of the lowest rolling element; Fill approximately 1/3 to 1/2 of the space with grease in the bearing box.
3. Frequent replacement of 60/32 32mm inner diameter bearing reason: Inappropriate internal clearance of bearings, such as shaft expansion when heated Solution: Select bearings with appropriate internal clearance, such as changing from standard grade to C3 or C3 to C4.
4. Frequent replacement of 60/32 32mm inner diameter bearing reason: Lubricant is contaminated by foreign objects such as dirt, sand, and carbon powder Solution: Clean the bearing box, replace with a new or improved oil seal, and inject fresh lubricant.
5. 60/32 32mm inner diameter bearing frequently replaced reason: Water, acid, paint, or other corrosive substances enter the bearing box Solution: Protective dust cover or dust ring for the device.
6. 60/32 32mm inner diameter bearing frequent replacement reason: the bearing box is distorted or the inner hole is out of round, too small Solution: Measure the size of the hole in the bearing box and turn it. Changing the non fixed end bearing from cylindrical roller bearing to Deep Groove Ball Bearing may cause the box hole to be tight or small.

7. 60/32 32mm inner diameter bearing frequently replaced reason: The bearing box was not cleaned before assembly Solution: Clean the bearing box and add fresh lubricant.
8. Frequent replacement of 60/32 32mm inner diameter bearing reason: Air flow causes bearing oil leakage, such as the airflow from the fan flowing through the bearing Solution: Install a wind deflector to divert the airflow, and use lubricating grease if possible.
9. 60/32 32mm inner diameter bearing frequently replaced reason: Bearing cross positioning Solution: Add a gasket between the bearing box and cover flange to release the preload on the bearing.
10. Frequent replacement of 60/32 32mm inner diameter bearing reason: There are two positioning bearings on one shaft, and excessive axial expansion leads to insufficient internal clearance of the bearing Solution: Move the end cover of either bearing box outward and use an inserted gasket to adjust the axial clearance of the bearing outer ring, so that the bearing can move freely axially.
11. Frequent replacement of 60/32 32mm inner diameter bearing reason: The journal is too small or the locking sleeve is not tight enough Solution: Spray the surface of the journal and grind it to the specified size or re lock the sleeve.
12. Frequent replacement of 60/32 32mm inner diameter bearing reason: Rotating oil seal or dust ring friction static components Solution: Check the running clearance of the rotating oil seal or dust ring to avoid friction and prevent misalignment.

13. Frequent replacement of 60/32 32mm inner diameter bearing reason: Excessive oil loss from the bearing box partition surface Solution: Using a thin layer of sealing paint will help prevent oil leakage. Do not use adjusting shims, replace the bearing housing if necessary.
14. Frequent replacement of 60/32 32mm inner diameter bearing reason: The machine is under unbalanced load, or the bearing hole is too large Solution: Rebalance the machine, or replace the bearing box with an accurate bore diameter.
15. Reason for frequent replacement of 60/32 32mm inner diameter bearing: uneven composite distribution on the bearing due to deformation of the shaft and bearing housing hole Solution: Rework the shaft and bearing housing hole to obtain appropriate shape and fit. But usually a new shaft or bearing box needs to be replaced.
16. Frequent replacement of 60/32 32mm inner diameter bearing reason: Improper shoulder support of the shaft causes bending of the shaft Solution: Rework the chamfer of the shaft to eliminate stress, may require adding shoulder snap rings.

17. Frequent replacement of bearings reason: Incorrect installation method of bearings, hammering of bearings Solution: Replace with new bearings, standardize shaft installation.
18. Frequent replacement of 60/32 32mm inner diameter bearing reason: Friction between shaft shoulder and bearing seal Solution: Rework shaft shoulder to eliminate friction.
19. Frequent replacement of 60/32 32mm inner diameter bearing reason: The constant oil level cup is installed too high or too low, or installed in the opposite position of the bearing rotation Solution: When in a stationary state, the oil level should not be higher than the center of the lowest rolling element, or the constant oil level cup should be installed in an accurate position consistent with the bearing rotation direction.
20. Reason for frequent replacement of bearings: deformation of the shaft and inner ring, uneven expansion of the bearing inner ring Solution: Rework the shaft chamfer to obtain appropriate support.
