Axial and radial bearing belong to the thrust bearings of rolling bearings, the other is angular contact bearings.Axial and radial bearing are installed perpendicular to the axial direction and can only withstand axial forces.A type of axial and radial bearing relative to a rolling bearing in the center.There are two types of axial contact bearings: one is ball bearings.The other type is roller bearings.
Concept and classification of axial and radial bearing:
1. Composition of axial and radial bearing (continued) In order to be suitable for certain special use requirements, some bearings may add or remove some parts.Bearing with grease seal Outer Ring bearing with stop ring Bearing no outer ring Bearing no inner ring Bearing neither outer ring nor inner ring Chapter 1 General concept and classification of Rolling Bearings
2. Function of four major parts of axial and radial bearing
The inner ring is usually fitted tightly with the shaft and rotates with the shaft.
The outer ring is usually matched with the housing hole of the bearing seat or the housing of the mechanical part to play a supporting role.
The axial and radial bearing body is arranged evenly between the inner and outer rings by means of the retainer, and its row, size and number directly determine the bearing capacity.
The cage separates the rolling body evenly and guides the rolling body to move on the correct track.Chapter 1 General concept and classification of rolling bearings
3.Type of roller ball (steel ball) spherical roller symmetric spherical roller asymmetrical spherical roller bearing bearing shape and shape, with high energy and small shadow number cylindrical roller needle tapered roller ring?
4.Type of cage: ferrous metal cage: nonmetal cage: nonferrous metal cage: low carbon steel, stainless steel, bakelized, nylon, 66 brass, bronze, aluminum alloy.
If you need axial and radial bearing or need any other bearings, please also contact me!
Contact: Leon
Email: nsk@zyslbearing.com
Skype: lh19881023
MP/Whatsapp: +8615098916271
