Pillow block bearings for sale cleaning and inspection

531 Published by admin Mar 25,2020

Cleaning and inspection of pillow block bearings for sale housing
Before mounting the pillow block bearings for sale seat, it should also be thoroughly cleaned and inspected.Scrape dirt away with a spatula inside the bearing seat, wipe dirt clean with a cloth dipped in gasoline or solvent, see whether there are cracks and sand holes, in order to prevent oil leakage in operation.The joint surface between the bearing cover and the bearing seat, the bearing seat and the bearing oil retaining ring shall be cleaned and checked with a plug. The clearance shall not be greater than 0.03mm.precision pillow block bearings for sale
Assemble for pillow block bearings for sale:
Both the single motor bearing and the multiple bearings of the unit shall be installed on the main longitudinal axis of the machine connected or on the longitudinal axis of the unit.The bearing center is measured by means of a wire and a wire hammer.(a wooden bar is stuck in the bearing arc, and a thin iron bar is nailed to the center of the bar to mark the center position).
Adjust the position of the shaft, starting from the bearing seat at the very edge, put a level on the pillow block bearings for sale seat to check the levelness of these planes.Use theodolite or level to check whether the plane of several axles is in the same horizontal plane, and use line hammer to find out whether the center of each bearing is on the same axis.pillow block bearings for sale
Adjust the pillow block bearings for sale seat according to the above method. In the process of eliminating the deviation, use the tool of jack to move the bearing seat. Do not use the method of hitting or hammering.The accuracy error of adjusting pillow block bearings for sale seat by this method is about 0.5~1.0 mm.It should be pointed out that the mounting adjustment of the bearing seat is only a preliminary adjustment, and should be adjusted to meet the requirements of the alignment of the axis when centering.After the presetting of the bearing seat, screw the screws evenly.
If you want to know more about pillow block bearings for sale or need any other bearings, please also contact me!
