Plain bearings types code is very simple, it is composed of the front type code, the middle size code and the rear detail change code. If there is a brand, it can be marked in front of the front type code.
Example:
GE50ES-2RS
GE: Type code, indicating GE series type joint bearings
50: Nominal inner diameter (not the actual inner diameter, because there is a tolerance)
E: Indicates that the outer ring of the bearing has an axial gap (the axial gap refers to a gap opened along the direction of the axis)
S: Indicates that the joint bearing has an oil groove and an oil hole
RS: Indicates that the bearing has a sealing ring on one side, so 2RS has sealing rings on both sides
GE60DO-2RS
GE: As above, type code, indicating GE series type joint bearings
60: Nominal inner diameter (not the actual inner diameter or =Tolerance)
DO: Same as ES, indicating that the outer ring of the bearing has an axial gap, and the inner and outer rings have oil grooves and oil holes
RS: The bearing has a seal ring on one side, so 2RS has seal rings on both sides
GE40UK-2RS
GE: Type code, indicating GE series spherical bearings
40: Nominal inner diameter (not referring to the actual inner diameter with tolerance)
UK: Same as E, indicating that the outer ring of the bearing has an axial gap, but it is a maintenance-free spherical bearing (self-lubricating spherical bearing)
RS: It means that the bearing has a seal ring on one side, and 2RS has seal rings on both sides
GE-DO plain bearings types GE4DO、GE5DO、GE6DO、GE8DO、GE10DO、GE12DO、GE15DO、GE17DO、GE20DO、GE25DO、GE30DO、GE35DO、GE40DO、GE45DO、GE50DO、GE60DO、GE70DO、GE80DO、GE90DO、GE100DO、GE110DO、GE120DO、GE140DO、GE160DO、GE180DO、GE200DO、GE220DO、GE240DO、GE260DO、GE280DO、GE300DO、GE320DO、GE340DO、GE360DO、GE380DO、GE400DO、GE420DO、GE440DO、GE460DO、GE480DO、GE500DO、GE530DO、GE560DO、GE600DO、GE630DO、GE670DO、GE710DO、GE750DO、GE800DO、GE850DO、GE900DO、GE950DO、GE1000DO。
GE-DO-2RS plain bearings types GE15DO-2RS、GE17DO-2RS、GE20DO-2RS、GE25DO-2RS、GE30DO-2RS、GE35DO-2RS、GE40DO-2RS、GE45DO-2RS、GE50DO-2RS、GE60DO-2RS、GE70DO-2RS、GE80DO-2RS、GE90DO-2RS、GE100DO-2RS、GE110DO-2RS、GE120DO-2RS、GE140DO-2RS、GE160DO-2RS、GE180DO-2RS、GE200DO-2RS、GE220DO-2RS、GE240DO-2RS、GE280DO-2RS、GE300DO-2RS。
GE-LO plain bearings types GE12LO、GE15LO、GE16LO、GE17LO、GE20LO、GE25LO、GE30LO、GE32LO、GE35LO、GE40LO、GE45LO、GE50LO、GE60LO、GE63LO、GE70LO、GE80LO、GE90LO、GE100LO、GE110LO、GE125LO、GE160LO、GE200LO、GE250LO、GE320LO。
GE-UK-2RS plain bearings types:GE15UK-2RS、GE17UK-2RS、GE20UK-2RS、GE25UK-2RS、GE30UK-2RS、GE40UK-2RS、GE50UK-2RS、GE60UK-2RS、GE70UK-2RS、GE80UK-2RS、GE90UK-2RS、GE100UK-2RS、GE110UK-2RS、GE120UK-2RS、GE140UK-2RS、GE160UK-2RS、GE180UK-2RS、GE200UK-2RS、GE220UK-2RS、GE240UK-2RS、GE260UK-2RS、GE280UK-2RS、GE300UK-2RS.
GE-ET-2RS plain bearings types:GE15ET-2RS、GE17ET-2RS、GE20ET-2RS、GE25ET-2RS、GE30ET-2RS、GE35ET-2RS、GE40ET-2RS、GE45ET-2RS、GE50ET-2RS、GE60ET-2RS、GE70ET-2RS、GE80ET-2RS、GE90ET-2RS、GE100ET-2RS、GE110ET-2RS、GE120ET-2RS 、GE140ET-2RS、GE160ET-2RS、GE180ET-2RS、GE200ET-2RS、GE220ET-2RS、GE240ET-2RS、GE260ET-2RS、GE280ET-2RS、GE300ET-2RS。
GEG-ET-2RS plain bearings types:GEG15ET-2RS、GEG17ET-2RS、GEG20ET-2RS、GEG25ET-2RS、GEG30ET-2RS、GEG35ET-2RS、GEG40ET-2RS、GEG45ET-2RS、GEG50ET-2RS、GEG60ET-2RS、GEG70ET-2RS、GEG80ET-2RS、GEG90ET-2RS、GEG100ET-2RS、GEG110ET-2RS、GEG120ET-2RS。
GE-XT-2RS plain bearings types:GE140XT-2RS、GE160XT-2RS、GE180XT-2RS、GE200XT-2RS、GE220XT-2RS、GE240XT-2RS、GE260XT-2RS、GE280XT-2RS、GE300XT-2RS。
GEG-XT-2RS plain bearings types:GEG100XT-2RS、GEG110XT-2RS、GEG120XT-2RS、GEG140XT-2RS、GEG160XT-2RS、GEG180XT-2RS、GEG200XT-2RS、GEG200XT-2RS、GEG220XT-2RS、GEG240XT-2RS、GEG260XT-2RS、GEG280XT-2RS。
GEC-XT plain bearings types:GEC320XT、GEC340XT、GEC360XT、GEC380XT、GEC400XT、GEC420XT、GEC440XT。
If you need any brand bearings or any models of bearings, please contact me!
