Thrust ball bearings are produced as single direction or double direction thrust ball bearings. They are designed to accommodate axial loads only and must not be subjected to any radial load.
ball bearing thrust load 51208 thrust ball bearing size 40x68x19 mm
Thrust ball bearings are classfied into those with flat seats or aligning seats depending on the shape of the outer ring sear(housing washer).They can sustain axial loads but no radial loads.
For single-direction Thrust Ball Bearings,pressed steel cages and machined brass cages usually used as shown.The cage in Double-Direction Thrust Ball Bearings are the same as those in Single-Direction Thrust Ball Bearings of the same diamteter series.
Single direction thrust ball bearings: consist of two washers with raceways, balls guided and cage. Washers have flat seating surfaces, and that is why they must be supported so that all balls can be evenly loaded. Bearings carry the axial load only in one direction. They are not able to carry radial forces.
- Double direction thrust ball bearings: have two cages with balls between the central shaft washer and two houding washers with flat seating surfaces. The shaft washer has raceways on both sides and is fixed on the journal. Bearings are able to carry only axial forces in both directions.
 |
 |
 |
 |
1,Q: Are you trading company or manufacturer ?
A: We are factory.
2,Q: How long is your delivery time for ball bearing thrust load 51208 thrust ball bearing?
A: Generally it is 3-5 days if the goods are in stock.or it is 15-20 days if the goods are not in stock,it is according to quantity.
3,Q: Do you provide samples for types of ball bearing thrust load 51208 thrust ball bearing?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
4,Q: What is your terms of payment for types of ball bearing thrust load 51208 thrust ball bearing?
A: Payment<=1000USD, 100% in advance.Payment>=1000USD,30% T/T in advance,pay the balance before shippment.
5, Q:Could you accept OEM and customize?
A:YES,we can customize for you according to sample or drawing.
6, Q: When can I get the price for bearing?
A: after we get your inquiry, usually within 2-6 hours.Urgent will be faster.
7,Q:How about your quality of types of ball bearing thrust load 51208 thrust ball bearing?
A:Our quality of bearings is based on ISO9001 and quality of bearing is our soul.
8, Q: What is the MOQ of your types of ball bearing thrust load 51208 thrust ball bearing?
A: Usually ≥1, According your demand.
9,Q: Will you check these products before shipment?
A: Yes, before shipment products will be strictly inspection on our factory QC Process System.We have a professional QC team.
10, Q: What will we do if If you are not satisfied with types of ball bearing thrust load 51208 thrust ball bearing?
A: If have any problem,Please contact us at first time, we will immediately processing.
 |
| If you need any brand bearings or any models of bearings, please contact me!Contact: Grace Email: ntn@llhbearing.com Skype:+8618668903871 MP/Whatsapp: +8618668903871 Wechat:GraceXu1234 |
|
Product Name
|
Thrust Ball Bearings
|
|
Model Number 1
|
51208
|
|
Inner Diameter (d1)
|
40mm
|
|
Outer Diameter (D)
|
68mm
|
|
Thickness (H)
|
19mm
|
|
Weight
|
0.28kg
|
|
Row
|
Single Row
|
|
Material
|
Chrome Steel (GCr15)
|
|
Item
|
Size (mm) | Load rating (kN) | Limit speed (r/min) | Weight | ||||
| d | D | T | Ca | Coa | Grease | Oil | (kg) | |
| 51100 | 10 | 24 | 9 | 10 | 14 | 6500 | 1000 | 0.02 |
| 51200 | 10 | 26 | 11 | 12.7 | 17.1 | 5700 | 8800 | 0.03 |
| 51101 | 12 | 26 | 9 | 10.3 | 15.4 | 6500 | 10000 | 0.022 |
| 51201 | 12 | 28 | 11 | 13.2 | 19 | 5400 | 8300 | 0.034 |
| 51102 | 15 | 28 | 9 | 10.5 | 16.8 | 6100 | 9400 | 0.024 |
| 51202 | 15 | 32 | 12 | 16.6 | 24.8 | 4900 | 7500 | 0.046 |
| 51103 | 17 | 30 | 9 | 10.8 | 18.2 | 6100 | 9400 | 0.028 |
| 51203 | 17 | 25 | 12 | 17.2 | 27.3 | 4900 | 7500 | 0.053 |
| 51104 | 20 | 25 | 10 | 14.2 | 24.7 | 5100 | 7900 | 0.04 |
| 51204 | 20 | 40 | 14 | 22.3 | 37.7 | 3900 | 6000 | 0.082 |
| 51304 | 20 | 47 | 18 | 35 | 55.8 | 3600 | 4500 | 0.092 |
| 51105 | 25 | 42 | 11 | 19.5 | 37.2 | 4400 | 6800 | 0.059 |
| 51205 | 25 | 47 | 15 | 27.8 | 50.4 | 3600 | 5500 | 0.12 |
| 51305 | 25 | 52 | 18 | 35.7 | 61.4 | 3100 | 4800 | 0.18 |
| 51405 | 25 | 60 | 24 | 55.6 | 89.4 | 2600 | 4000 | 0.34 |
| 51106 | 30 | 47 | 11 | 20.4 | 42.2 | 4300 | 6600 | 0.068 |
| 51206 | 30 | 52 | 16 | 29.3 | 58.2 | 3400 | 5200 | 0.15 |
| 51306 | 30 | 60 | 21 | 42.8 | 78.7 | 2700 | 4200 | 0.27 |
| 51406 | 30 | 70 | 28 | 72.8 | 126 | 2200 | 3400 | 0.53 |
| 51107 | 35 | 52 | 12 | 20.4 | 44.7 | 3900 | 6000 | 0.09 |
| 51207 | 35 | 62 | 18 | 39.2 | 78.2 | 2900 | 4500 | 0.22 |
| 51307 | 35 | 68 | 24 | 55.5 | 105 | 2400 | 3700 | 0.39 |
| 51407 | 35 | 80 | 32 | 87.1 | 155 | 1900 | 2900 | 0.79 |
| 51108 | 40 | 60 | 13 | 26.9 | 62.8 | 3400 | 5300 | 0.12 |
| 51208 | 40 | 68 | 19 | 46.9 | 98.3 | 2700 | 4200 | 0.27 |
| 51308 | 40 | 78 | 26 | 69.3 | 135 | 2100 | 3300 | 0.55 |
| 51408 | 40 | 90 | 36 | 113 | 205 | 1700 | 2600 | 1.14 |
| 51109 | 45 | 65 | 14 | 27.8 | 69.1 | 3200 | 5000 | 0.15 |
| 51209 | 45 | 73 | 20 | 47.7 | 105 | 2600 | 4000 | 0.32 |
| 51309 | 45 | 85 | 28 | 80 | 163 | 1900 | 3000 | 0.69 |
| 51409 | 45 | 100 | 39 | 130 | 242 | 1500 | 2300 | 1.47 |
