Produce insulated bearings inhouse NU260 bearing can avoid the damage caused by electrical corrosion, so they are more reliable to operate in the motor than ordinary bearings.It is more cost effective and reliable than other insulation methods, such as shaft or shell insulation.
Produce insulated bearings inhouse NU260 bearing
Produce insulated bearings inhouse NU260 bearing adopts special spraying technology, and it is sprayed on the outer surface of the bearing with high quality plastic film, which has strong binding force with the base body and good insulation performance, which can avoid the electric corrosion of the bearing caused by induction current, prevent the damage of current to the grease,rolling body and raceway,and improve the service life of the bearing.
Characteristics for Produce insulated bearings inhouse NU260 bearing:
The process of Produce insulated bearings inhouse NU260 bearing has been continuously improved, and in the insulating bearing, there is a coating of 100 p m thick on the surface of the outer or inner ring, which can withstand voltage up to 1000 V DC.The special spraying process can form a layer of uniform thickness and highly uniform adhesion, which can be further treated so that it can be free from the influence of moisture and humidity.
FAQ:
1,Q: Are you trading company or manufacturer?
A: We are factory.
2,Q: How long is your delivery time for Produce insulated bearings inhouse NU260 bearing?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3,Q: Do you provide samples for Produce insulated bearings inhouse NU260 bearing? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
4,Q: What is your terms of payment for Produce insulated bearings inhouse NU260 bearing?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,pay the balance before shippment.
5, Q:Could you accept OEM and customize for bearing?
A:YES,we can customize for you according to sample or drawing.
6, Q: When can I get the price?
A: after we get your inquiry, usually within 2-6 hours. Urgent will be faster.
7,Q:How about your quality of Produce insulated bearings inhouse NU260 bearing?
A:Our quality of bearings is based on ISO9001 and quality of bearing is our soul.
8, Q: What is the MOQ?
A: Usually ≥1, According your demand.
9,Q: Will you check these products before shipment?
A: Yes, before shipment products will be strictly inspection on our factory QC Process System.We have a professional QC team.
10, Q: What will we do if If you are not satisfied with the product?
A: If have any abnormal, Please contact us at first time, we will immediately processing.
If you need Produce insulated bearings inhouse NU260 bearing or any models of bearings, please contact me!
Contact: Leon
Email: nsk@zyslbearing.com
Skype: lh19881023
MP/Whatsapp: +8615098916271
Wechat:leon15098916271
| Product Name | Produce insulated bearings inhouse NU260 bearing |
| Material | hybrid ceramic, Si3N4 or ZrO2 ball , chrome steel or stainless steel ring |
| Brand | LLH or OEM |
| Standard | DIN GB ISO JIS BA ANSI |
| Grade | ABEC-3 ABEC-5 , ABEC-7, ABEC-9 |
| Clearance | C0, C3 ,C5 |
| Package | carton package |
| Used | Machine |
| Principal dimensions | Basic load ratings | Fatigue load limit | Speed ratings | Mass | Designation | ||||
| dynamic | static | Reference speed | Limiting speed | ||||||
| d | D | B | C | C0 | Pu | ||||
| mm | kN | kN | r/min | kg | – | ||||
| 70 | 150 | 35 | 111 | 68 | 2,75 | 9500 | 6300 | 2,5 | 6314/C3VL0241 |
| 75 | 130 | 25 | 68,9 | 49 | 2,04 | 10000 | 6700 | 1,2 | 6215/C3VL0241 |
| 75 | 160 | 37 | 119 | 76,5 | 3 | 9000 | 5600 | 3,05 | 6315/C3VL0241 |
| 80 | 140 | 26 | 72,8 | 55 | 2,2 | 9500 | 6000 | 1,4 | 6216/C3VL0241 |
| 80 | 170 | 39 | 130 | 86,5 | 3,25 | 8500 | 5300 | 3,55 | 6316/C3VL0241 |
| 85 | 150 | 28 | 87,1 | 64 | 2,5 | 9000 | 5600 | 1,75 | 6217/C3VL0241 |
| 85 | 180 | 41 | 140 | 96,5 | 3,55 | 8000 | 5000 | 4,1 | 6317/C3VL0241 |
| 90 | 160 | 30 | 101 | 73,5 | 2,8 | 8500 | 5300 | 2,4 | 6218/C3VL0241 |
| 90 | 190 | 43 | 151 | 108 | 3,8 | 7500 | 4800 | 4,9 | 6318/C3VL0241 |
| 95 | 170 | 32 | 114 | 81,5 | 3 | 8000 | 5000 | 2,5 | 6219/C3VL0241 |
| 95 | 200 | 45 | 159 | 118 | 4,15 | 7000 | 4500 | 5,65 | 6319/C3VL0241 |
| 100 | 180 | 34 | 127 | 93 | 3,35 | 7500 | 4800 | 3,15 | 6220/C3VL0241 |
| 100 | 215 | 47 | 174 | 140 | 4,75 | 6700 | 4300 | 7 | 6320/C3VL0241 |
| 110 | 200 | 38 | 151 | 118 | 4 | 6700 | 4300 | 4,25 | 6222/C3VL0241 |
| 110 | 240 | 50 | 203 | 180 | 5,7 | 6000 | 3800 | 9,65 | 6322/C3VL0241 |
| 120 | 215 | 40 | 146 | 118 | 3,9 | 6300 | 4000 | 5,2 | 6224/C3VL0241 |
| 120 | 260 | 55 | 208 | 186 | 5,7 | 5600 | 3400 | 12,5 | 6324/C3VL2071 |
| 130 | 230 | 40 | 156 | 132 | 4,15 | 5600 | 3600 | 5,75 | 6226/C3VL2071 |
| 130 | 280 | 58 | 229 | 216 | 6,3 | 5000 | 3200 | 15,2 | 6326/C3VL2071 |
| 140 | 300 | 62 | 251 | 245 | 7,1 | 4800 | 3000 | 18,5 | 6328/C3VL2071 |
| 150 | 270 | 45 | 174 | 166 | 4,9 | 5000 | 3200 | 9,8 | 6230/C3VL2071 |
| 150 | 320 | 65 | 276 | 285 | 7,8 | 4300 | 2800 | 23 | 6330/C3VL2071 |
