Radial cylindrical roller bearings NU319 bearing consist of cages, rollers and are guided by two capped edges on a ring. It is a separable bearing and convenient to mount and dismount. Its merit is especially unique under the condition that the interference is required and assorted with inner ring, outer ring and housing.
Radial cylindrical roller bearings NU319 bearing
Radial cylindrical roller bearings NU319 bearing can normally withstand the radial load, on the other hand, single-row cylindrical roller bearing with ribbed inner ring and outer ring can take smaller axial load or intermittent axial load, this kind of Radial cylindrical roller bearings NU319 bearing has a larger carrying capacity of axial load in comparison with the deep groove ball bearing.The structure of the bearing ensures that it runs very well under high rotational speed.
Types for Radial cylindrical roller bearings NU319 bearing:
1.Single-row cylindrical roller bearing including NU, NJ, NUP, N and NF
2.Double-row cylindrical roller bearing such as NNU, NN, etc.
3.Four-row cylindrical roller bearing
N type:
The inner ring has two integral flanges and the outer ring is without flanges. Axial displacement of the shaft with respect to the housing can be accommodated in both directions within the bearing itself. The bearings are therefore used as non-locating bearings.
NU type:
The outer ring of bearings of the NU design has two integral flanges and the inner ring is without flanges. Axial displacement of the shaft with respect to the housing can be accommodated in both directions within the bearing itself.
NJ type:
The outer ring has two integral flanges and the inner ring one integral flange. The bearings are therefore suitable for the axial location of a shaft in one direction.
NF type:
The outer ring has one integral flange and the inner ring two integral flanges.
NUP type:
The outer ring has two integral flanges and the inner ring one integral flange and one non-integral flange in the form of a loose flange ring. The bearings can be used as locating bearings, i.e. they can provide axial location for a shaft in both directions.
RN type:
No outer ring and the inner ring two integral flanges.
NN type:
NN type bearing without ribs on outer ring,there is a wall in the midel of between both sides of inner ring. It can make shaft relative bearing between the axial displacement generated in both directions.
FAQ:
1,Q: Are you trading company or manufacturer?
A: We are factory.
2,Q: How long is your delivery time for Radial cylindrical roller bearings NU319 bearing?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3,Q: Do you provide samples for Radial cylindrical roller bearings NU319 bearing? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
4,Q: What is your terms of payment for Radial cylindrical roller bearings NU319 bearing?
A: Payment<=1000USD,100% in advance.Payment>=1000USD, 30% T/T in advance,pay the balance before shippment.
5, Q:Could you accept OEM and customize for Radial cylindrical roller bearings NU319 bearing?
A:YES,we can customize for you according to sample or drawing.
6, Q: When can I get the price for Radial cylindrical roller bearings NU319 bearing?
A: after we get your inquiry,usually within 2-6 hours.Urgent will be faster.
7,Q:How about your quality of Roller bearing slides guide roller bearing?
A:Our quality of bearings is based on ISO9001 and quality of bearing is our soul.
8, Q: What is the MOQ for Radial cylindrical roller bearings NU319 bearing?
A: Usually ≥1, According your demand.
9,Q: Will you check these Radial cylindrical roller bearings NU319 bearing before shipment?
A: Yes, before shipment products will be strictly inspection on our factory QC Process System.We have a professional QC team.
10, Q: What will we do if If you are not satisfied with the Radial cylindrical roller bearings NU319 bearing?
A: If have any abnormal, Please contact us at first time, we will immediately processing.
If you need Radial cylindrical roller bearings NU319 bearing or any models of bearings, please contact me!
Contact: Leon
Email: nsk@zyslbearing.com
Skype: lh19881023
MP/Whatsapp: +8615098916271
Wechat:leon15098916271
Ring material | Chrome Steel GCr15 |
Brand | LLH or OEM |
Precision | P0,P6,P5,P4 |
Clearance: | C2 ,C3, C4 |
Quality standard | ISO9001:2008 |
Samples | Available |
Service | OEM |
Diameter(mm) | cage | |
Item No. | Old item No. | d*D*B |
NU1004M | 32104H | 20*42*12 |
NU1005M | 32105H | 25*47*12 |
NU1006M | 32106H | 30*55*13 |
NU1010M | 32110H | 50*80*16 |
NU1011M | 32111H | 55*90*18 |
N1012M | 2112H | 60*95*18 |
NJ1012M | 42112H | 60*95*18 |
N1018M | 2118H | 90*140*24 |
NU1018M | 32118H | 90*140*24 |
NJ1018M | 42118H | 90*140*24 |
N1019M | 2119H | 95*145*24 |
NU1019M | 32119H | 95*145*24 |
NJ1019M | 42119H | 95*145*24 |
N1020M | 2120H | 100*150*24 |
NU1020M | 32120H | 100*150*24 |
NJ1020M | 42120H | 100*150*24 |
N1022M | 2122H | 110*170*28 |
NU1022M | 32122H | 110*170*28 |
NJ1022M | 42122H | 110*170*28 |
N1024M | 2124H | 120*180*28 |
NU1024M | 32124H | 120*180*28 |
NJ1024M | 42124H | 120*180*28 |
N1026M | D2126 | 130*200*33 |
NU1026M | C2126 | 130*200*33 |
NU1030 | 32130H | 150*225*35 |
NJ1030M | 42130H | 150*225*35 |
NU1030Q1/YHA6 | 150*225*35 | |
RNU1030M | 292130 | 169.5*225*35 |
