25*40*59mm Best Quality Long Life Linear Ball Bearing LME25UU shaft bushing design

Linear bearing shaft bushing design consumption also has its limitations, is the main bearing impact load ability is poor, and poor bearing capacity also, second linear bearing vibration and noise is bigger when high speed movement.


Product Specification:

  • Model LME25UU
  • Size 25*40*59mm
  • Brand LLH or OEM
  • Original China
See Price

25*40*59mm Best Quality Long Life Linear Ball Bearing LME25UU shaft bushing design

LME25UU bearingshaft bushing design lme 25 uu Linear bearing is a kind of linear motion system for straight line travel used with cylindrical shaft.Due to coat point contact ball bearing with bearing, steel ball roll with minimum friction resistance, so the linear bearing small friction, and relatively stable, not over bearing speed changes, and can obtain high sensitivity, high precision of stationary linear motion.Linear bearing consumption also has its limitations, is the main bearing impact load ability is poor, and poor bearing capacity also, second linear bearing vibration and noise is bigger when high speed movement.Linear bearing automatic fast easy optimal selection are included.lme 25 uu bearingThese shaft bushing design lme 25 uu are the most common type and are used in a wide variety of applications. Such as Steel Industry , Mining & Construction , Papermaking Machinery , Wind Turbines , Machine Tools , Gearboxes , Electric Motors , Pumps & Compressors , Injection Molding , Motorcycles , Railways, etc.high temperature linear bearings

FAQ:
1,Q: Are you trading company or manufacturer?
A: We are factory.
2,Q: How long is your delivery time for about shaft bushing design lme 25 uu ?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3,Q: Do you provide samples for about shaft bushing design lme 25 uu ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
4,Q: What is your terms of payment for about shaft bushing design lme 25 uu ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance,pay the balance before shippment.
5, Q:Could you accept OEM and customize for products?
A:YES,we can customize for you according to sample or drawing.
6, Q: When can I get the price of about shaft bushing design lme 25 uu ?
A: after we get your inquiry, usually within 2-6 hours. Urgent will be faster.
7,Q:How about your quality of your products?
A:Our quality of bearings is based on ISO9001 and quality of bearing is our soul.
8, Q: What is the MOQ for about shaft bushing design lme 25 uu?
A: Usually ≥1, According your demand.
9,Q: Will you check these about shaft bushing design lme 25 uu before shipment ?
A: Yes, before shipment products will be strictly inspection on our factory QC Process System.We have a professional QC team.
10, Q: What will we do if If you are not satisfied with the shaft bushing design lme 25 uu ?
A: If have any abnormal, Please contact us at first time, we will immediately processing.

If you need any brand bearings or any models of bearings, please contact me!

Contact: Grace
Email: ntn@llhbearing.com
Skype:+8618668903871
MP/Whatsapp: +8618668903871
Wechat:GraceXu1234

  Product Name   Hot Sale Bearing for 3D Printer Linear Bearing LME25UU
      Model Number  LME25UU
     Inner Diameter 25MM
     Outer Diameter  50MM
         Breadth  59MM
     Product Material Chrome steel

high speed linear bearing

Model Inner size(mm) Outer size(mm) Length(mm) Weight(kg/pc)
LM6UU 6 12 19 0.007
LM8UU 8 15 24 0.015
LM10UU 10 19 29 0.03
LM12UU 12 21 30 0.032
LM13UU 13 23 32 0.043
LM16UU 16 28 37 0.069
LM20UU 20 32 42 0.087
LM25UU 25 40 59 0.22
LM30UU 30 45 64 0.25
LM35UU 35 52 70 0.39
LM40UU 40 60 80 0.585
LM50UU 50 75 100 1.58
LM60UU 60 90 110 1.86
LM80UU 80 120 140 4.42
Model Inner size(mm) Outer size(mm) Length(mm) Weight(kg/pc)
LM6LUU 6 12 35 0.016
LM8LUU 8 15 45 0.031
LM10LUU 10 19 55 0.062
LM12LUU 12 21 57 0.08
LM13LUU 13 23 61 0.09
LM16LUU 16 28 70 0.145
LM20LUU 20 32 80 0.18
LM25LUU 25 40 112 0.44
LM30LUU 30 45 123 0.58
LM35LUU 35 52 135 0.795
LM40LUU 40 60 154 1.17
LM50LUU 50 80 192 2.1
LM60LUU 60 90 211 3.5

high quality linear bearing

Jinan Maolei bearing Co.,Ltd. is located in the “Spring City” Jinan. We insist on the philosophies of “integrity” and “pragmatic & win-win business”. We also adhere to the “people-oriented” and “advancing” enterprise spirit . “Quality first and customers utmost” is honored as our enterprise concept.The core products of Jinan Maolei bearing Co,.Ltd. We have our own brand “LLH”,we sincerely welcome friends from all over the world come to visit our company and talk on business,we adhere to the concept of”survival of high quality”,and provide excellent service for customers.precision bearing
