thrust needle roller bearing is such a manner that the needles (rollers) with cage are set up in the space between rollway and collar and the cage reliably guides and clamps a lot of rolling bodies.
About thrust needle roller bearings:
Thrust needle roller bearings are comosed of a set of tray ring gaskets combined with retainer with roller bearings.The stand leads and holds many rolling elements.The thrust needle bearings or thrust-cylindrical roller bearings can support the bearings with the axial directional load and so the can be used as the bearings with good rigidity and minium axial occupied spaces.
If the surface of the adjacent parts can be used as a tray for the rolling needles and the holding stand assembly should be recommended when the support space is big enough so that a small axial cross sectional altitude can be achieved.Same effectiveness can be ensured in different cases when combined with the relatively thicker ring gaskets of LS,GS,WS,ZS series.The applicable gaskets series of AS,LS,GS,WS,ZS are optional and will be ordered sparately by the buyers.
Thrust needle roller bearings are units comprising axial needle rollers and cage assemblies and axial bearing washers with a centring spigot.Thrust needle roller bearings are able to accommodate heavy axial loads. They are insensitive to shock loads and provide a high degree of bearing units stiffness within a minimum axial space. They represent unidirectional bearings and can accommodate axial loads acting in one direction only.
Model Number | AXK120155 |
Brand Name | LLH |
Structure | Spherical Thrust Roller Bearing |
Type | Roller |
Precision | P0,P6,P5,P4,P2 |
Clearance | C2,Cn,C3,C4 |
Vibration | V1,V2,V3,V4 |
Noise level | Z1,Z2,Z3,Z4 |
Rings Material | Chrome steel ,Carbon steel, Stainless steel |
Cages Material | Nylon ,Steel , Brass |
Certifications | ISO 9001:2008 |
Place of Origin | China (Mainland) |
FAQ
1,Q: Are you trading company or manufacturer ?
A: We are factory.
2,Q: How long is your delivery time for thrust needle roller bearings axk7095 ?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3,Q: Do you provide samples for thrust needle roller bearings axk7095? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
4,Q: What is your terms of payment for thrust needle roller bearings axk7095?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,pay the balance before shippment.
5, Q:Could you accept OEM and customize?
A:YES,we can customize for you according to sample or drawing.
6, Q: When can I get the price?
A: after we get your inquiry, usually within 2-6 hours. Urgent will be faster.
7,Q:How about your quality of thrust needle roller bearings axk7095?
A:Our quality of bearings is based on ISO9001 and quality of bearing is our soul.
8, Q: What is the MOQ of your thrust needle roller bearings axk7095?
A: Usually ≥1, According your demand.
9,Q: Will you check these thrust needle roller bearings axk7095 before shipment?
A: Yes, before shipment products will be strictly inspection on our factory QC Process System.We have a professional QC team.
10, Q: What will we do if If you are not satisfied with the thrust needle roller bearings axk7095?
A: If have any abnormal, Please contact us at first time, we will immediately processing.
If you need any brand bearings or any models of bearings, please contact me!
Contact: Grace
Email: ntn@llhbearing.com
Skype:+8618668903871
MP/Whatsapp: +8618668903871
Wechat:GraceXu1234
Type
|
Needle roller bearing
|
Model
|
AXK7095
|
Brand
|
LLH/OEM
|
Fw (mm)
|
70mm
|
Material
|
Chrome steel
|
D (mm)
|
95mm
|
Seal type
|
Open
|
C (mm)
|
4mm
|
Precision rate
|
P0, P6
|
Payment Term
|
T/T,Paypal
|
Part No. | ID/mm | OD/mm | W/mm | Weight/g | Load Rating(KN) | Limited Speed (r/min) |
|
Cr/KN | Cor/KN | ||||||
AXK0414 | 4 | 14 | 2 | 0.7 | 4.4 | 8 | 21000 |
AXK0515 | 5 | 15 | 2 | 0.8 | 4.75 | 9.2 | 21000 |
AXK0619 | 6 | 19 | 2 | 1 | 6.8 | 15.5 | 19000 |
AXK0821 | 8 | 21 | 2 | 2 | 7.8 | 19.4 | 18000 |
AXK1024 | 10 | 24 | 2 | 3 | 9.2 | 25.5 | 17000 |
AXK1226 | 12 | 26 | 2 | 3 | 9.9 | 29 | 15000 |
AXK1528 | 15 | 28 | 2 | 4 | 11.3 | 36 | 13000 |
AXK1730 | 17 | 30 | 2 | 4 | 11.9 | 39.5 | 12000 |
AXK2035 | 20 | 35 | 2 | 5 | 13.1 | 46.5 | 10000 |
AXK2542 | 25 | 42 | 2 | 7 | 14.7 | 58 | 8500 |
AXK3047 | 30 | 47 | 2 | 8 | 16.3 | 70 | 7500 |
AXK3552 | 35 | 52 | 2 | 10 | 17.8 | 81 | 6500 |
AXK4060 | 40 | 60 | 3 | 16 | 28 | 114 | 6000 |
AXK4565 | 45 | 65 | 3 | 18 | 30 | 128 | 5000 |
AXK5070 | 50 | 70 | 3 | 20 | 32 | 143 | 4800 |
AXK5578 | 55 | 78 | 3 | 28 | 38 | 186 | 4300 |
AXK6085 | 60 | 85 | 3 | 33 | 44.5 | 234 | 4000 |
AXK6590 | 65 | 90 | 3 | 35 | 46.5 | 255 | 3700 |
AXK7095 | 70 | 95 | 4 | 60 | 54 | 255 | 3500 |
AXK75100 | 75 | 100 | 4 | 61 | 55 | 265 | 3300 |
AXK80105 | 80 | 105 | 4 | 63 | 56 | 280 | 3100 |
AXK85110 | 85 | 110 | 4 | 67 | 28 | 290 | 3000 |
AXK90120 | 90 | 120 | 4 | 86 | 73 | 405 | 2700 |
AXK100135 | 100 | 135 | 4 | 104 | 91 | 560 | 2500 |
AXK110145 | 110 | 145 | 4 | 122 | 97 | 620 | 2300 |
AXK120155 | 120 | 155 | 4 | 131 | 102 | 680 | 2100 |
AXK130170 | 130 | 170 | 5 | 205 | 133 | 840 | 1900 |
AXK140180 | 140 | 180 | 5 | 219 | 138 | 900 | 1800 |
AXK150190 | 150 | 190 | 5 | 232 | 143 | 960 | 1700 |
AXK160200 | 160 | 200 | 5 | 246 | 148 | 1020 | 1600 |
