Can thrust bearing load capacity withstand radial loads?
(1) Thrust bearing load capacity cannot bear radial load:
Different types of thrust bearing load capacity size is different, some can two-way axial load bearing, can only one-way load bearing, such as 52000 can bear two-way axial load.
(2) Thrust ball bearing is designed to bear thrust load when running at high speed.
It consists of a gasket-like ring with a ball rolling groove.Because the ring is cushion, the thrust bearing load capacity is divided into two types: flat base cushion and self-aligning spherical cushion.In addition, the bearing can withstand axial load, but not radial load.
(3)Unidirectional thrust bearing load capacity can bear unidirectional axial load. Bidirectional thrust ball bearing, can withstand bidirectional axial load.
Wherein the shaft ring is matched with the shaft. The mounting surface of the seat ring is spherical bearing, with self-aligning performance, which can reduce the impact of installation errors. Thrust ball bearing can not bear radial load, the limit speed is low.
(4)Unidirectional thrust bearing load capacity can only bear loads in one direction
If the load is carried in two directions, two-way thrust ball bearings must be selected.
Thrust ball bearings must apply minimum load or preload. When the shaft is perpendicular, the weight of the shaft usually exceeds the minimum load. At this time, due to the influence of the axial load in the opposite direction, the load of the action may be reduced.
When the thrust ball bearing runs at high speed, the contact Angle between the ball and the radial plane of the raceway will be affected by centrifugal force, resulting in the sliding of the ball relative to the raceway. The adhesive wear caused by this sliding can damage the bearing.
If you want to know more detail for thrust bearing load capacity or need any other bearings, please feel free to contact me to get more detail!
